The traction tables have been specifically designed for lumbar and cervical traction. They feature an integral rolling top design to facilitate effective traction procedures. The tables are available seperately with machine mount or as part of a package with traction machine, flexion stool, all harnesses and neck pillow.
CHOICE OF MODELS AVAILABLE
- Electric Traction Table with machine mount
- Hydraulic Traction Table with machine mount
- Electric Traction Package
- Hydraulic Traction Package
STANDARD MODEL SPECIFICATION - TRACTION TABLES
- Safe working load and lifting capacity (from minimum height) of 240 kgs (528lbs=37.7 stone)
- Integral rolling top design to provide effective application of traction forces
- Adjustable height mount for traction machine with offset positioning for changing angle of traction application
- Adjustable angle backrest from horizontal to +80 degrees positive
- Adjustable angle head/foot section from -25 degrees to +75 degrees
- Head section includes breathing hole and plug
- The power assisted backrest and foot sections incorporate anti-trap desgin
- Choice of manual or electric height elevation
- Excellent height range from 50-101cm (20"-40")
- Retractable wheel design with adjustable foot for stability on uneven surfaces
- Fixation point for optional cervical traction accessory
- Purpose made precision bearings on all pivot points
- Hand switch fitted as standard on electric models
- Standard width 70cm (28")
STANDARD MODEL SPECIFICATION - SM 12 TRACTION MACHINE
A very versatile and easy to operate traction machine with both static and intermittent treatment modes. The SM12 Traction machine features variable speed control with clear displays of all treatment settings and is available seperately or as part of a traction package with table and accessories.
- Choice of intermittent or static traction modes
- Variable speed control with quiet operation thorughout treatment period
- Minimum and maximum force settings 2.5 - 91kgs (5.5lbs - 200lbs)
- Variable hold and rest times from 0 - 99 seconds
- Clear displays of all set treatment perimeters
- Patient safety switch with adjustable alarm
- Supplied with spreader bar
- CE marked and registered - Class 2A medical device
- Dimensions W27cm x H27cm x D34cm
- Weight 13.5 kgs (30lbs)
OPTIONAL COUCH ACCESSORIES
- Single foot switch for electric models
- Cervical in sitting accessory
- Pelvic (Lumbar) traction harness
- Thoracic traction harness
- Thoracic harness straps (pair)
- Cervical traction head halter
- Cervical pillow
- Flexicon stool
- Spreader bar
